1 Motor 1 Diesel 138PSI Head 200GPM End Suction Fire Pump

Place of Origin China
Brand Name CNP NM FIRE
Certification UL FM NFPA20 CE
Model Number ESF50-26
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Standard Export Package
Delivery Time 75 Working Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Use Fire Fighting Casing Ductile Cast Iron
Bearing Housing Cast Iron Speed 2950 Rpm
Head 138 PSI Capcity 200 GPM
Leave a Message
Product Description

200 GPM End Suction Fire Pump Assembly 1 Motor 1 Diesel Fire Pump System





Main Configurations:



Motor assembly F-TDC286TS40U2B 3/50/380
Vacuum Manometer Φ100 -1-1.5bar
Pressure Gauge Φ100 0-16bar
Pump assembly ESF50/26 200gpm@138psi
Circulation safety valve Cla-Val 55L-60 100-300psi 3/4"
Relief Cone 2"-2.5"
Relief Valve 2050B-4KG1 Angle 2” 20-200psi
Diesel engine
assembly
NM4-90 2950rpm/38kw
The diesel auxiliary control cabinet NM.EnI.Ab-ETS-24-L2
Fuel Tank 400L S.W



1 Motor 1 Diesel 138PSI Head 200GPM End Suction Fire Pump 0








1 Motor 1 Diesel 138PSI Head 200GPM End Suction Fire Pump 1





Applications

Deep well, irrigation, sumps, condensate, can pump requirements, fire service, municipal, industrial



The VTP pump line is normally designed to operate in wells or sumps. Its bowl assembly consists primarily of a suction case or bell, one or more pump bowls and a discharge case. The pump bowl assembly is positioned in the sump or well at a depth to provide the proper submergence.


Operation Limits


Capacity up to 13,636 m³/h (60,000 U.S. gpm)
Head up to 762 m (2,500 ft)
Maximum Pressure 74 bar (1,080 psi)
Temperature 0 to 121 ºC (32 to 250 ºF)
Applications Deep well, irrigation, sumps, condensate, can pump requirements, fire service, municipal, industrial



Advantage:



First-Class international technical standards.



CNP NM FIRE is the first member of NFPA from China pump's manufacturers.and won the UL,FM international fire certification for fire pump products.



First-Class testing and inspection equipment.



UL certification represents the world's highest technical standards of fire certification,but also means that certified fire products must withstand the most extreme,harsh test process,the purpose of certification designed to verify whether the product meets the performance,safety and quality requirements,so as to achieve the purpose of property protection.


NM fire obtained fire diesel engine UL1247 and fire pump UL448 witnessed laboratory accreditation,fully proved that the company in terms of hardware and software strength,are to meet the strict requirements of UL certification.



Service

1. Reply within 24 hours.
2. High-quality products and the most reasonable price
3. Data and chemical technology support.
4. Professional team service
5. Customiszed production for different package
