Skid Mounted Fire Fighting Pump Set 500GPM / 165PSI For Oil Repositories
| Place of Origin | China |
|---|---|
| Brand Name | CNP NM FIRE |
| Certification | UL/FM |
| Model Number | package |
| Minimum Order Quantity | 1set |
| Price | Negotiation |
| Packaging Details | Export Packing |
| Delivery Time | 30-45 Working Days |
| Payment Terms | L/C, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Certification | UL/FM/NFPA 20 | Pump | SCF125-80-350 (5x3") |
|---|---|---|---|
| Casing： | Ductile Cast Iron | Flow | 500GPM |
| Head | 165PSI | Color | Red |
Product Description
NFPA20 Accordance 500GPM @ 165PSI Skid Mounted Fire Pump With Horizontal Split Case Fire Pump Sets By UL/FM Listed
NM designs and manufactures custom and pre-engineered skid package fire pump systems. These systems are factory assembled and tested, leaving only pipe connections, power connections and structural base grouting to be completed on site. All fire pump packages built to NFPA 20 standards with UL listed / FM approved components.
This all-in-one solution objetive is to eliminate the complexity and problems of on site assembly. We ensure all package skids meet inspection requirements of local National Building Code, NFPA 20 Standards and Insurance companies.
Fire pump packages also reduce the cost of assembly, quick installation means less work and time spent on installation, and your fire pump system can be fully operational very quickly. This fire protection pumping solution that NM provides is a superior quality fire system with reliability and inbuilt safety.
Advantages:
- We are the first member of NFPA among Chinese pump manufacturers. The production of our fire pump groups is strictly in accordance with NFPA20.
- We are the first manufacturer in the world who have both UL/FM certification for fire pump and the fire-fighting diesel engine, also the only UL Witness laboratory in Asia for fire-fighting pump and fire-fighting diesel engine.
- We have applied dozens of patents.
- We have young team, top experts.
Parameters:
| HEAD |
PUMP MODEL |
SPEED | MAX SHAFT POWER | MOTOR DRIVER | DIESEL ENGINE DRIVER | ||||||||||
| PSI | FEET | METER | RPM | HP | KW |
MODEL (TECHTOP&UL) |
HP | KW |
MODEL (NM&UL) |
HP | KW | MODEL(DE MAAS&FM) | HP | KW | |
| 165 | 381 | 116 | SCF125-80-350 (5x3") |
2980 (50Hz) |
114 | 84.9 | T 280M-2 (IEC/TEFC) |
120 | 90 | NM6-102 | 126 | 94 | IF05ATH-F | 130 | 97 |
NM package fire pump system consists of pumps, driver, controllers and accessories mounted on a common base frame. High quality UL / FM certified components are used in these systems complying with the requirements of NFPA 20. All necessary wiring between controllers and drivers are done at factory prior to shipment. The automatic air release valve, casing relief valve, suction gauge & discharge gauge are mounted on fire pumps and other accessories are mounted on pre-constructed interconnecting piping as required by NFPA 20. Pressure sensing lines are pre-installed on Electric, Diesel, and Jockey Controllers as per NFPA 20 requirements.
These systems are subjected to rigorous performance tests at factory as per UL, FM & NFPA standards to ensure proper performance of the system as per the design requirements. For completing the installation of these pre-engineered 'ready to install' packages the installing contractor only needs to grout the structural base, connect the suction & discharge pipes and incoming power.
Performance Ranges:
|
|
Q: 500-4000GPM | H:100-190PSI |
|
|
Q: 500-4000GPM | H:100-190PSI |
|
|
Q:20-500L/S | H:0.42-2.0Mpa |
|
|
Q: 300-8000GPM | H:60-300PSI |
Pump types:
Split-case pump, Jockey pump, In-line pump
Configuration types:
1.Electric motor driven fire pump sets
2.Diesel engine driven fire pump sets
3.jockey pump sets
Standard:
UL Listed
FM Approval
NFPA20 Package
Service:
| 1. Any inquiries will be replied within 12 hours. |
| 2. Dedicated to high quality, stable supply and considerate service. |
| 3. Strict on raw material selection. |
