Skid Mounted Horizontal Split Case Pump

Place of Origin China
Brand Name NM Fire
Certification UL / FM / NFPA 20 / CE
Model Number SCF150-125-250-100
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Standard Export Seaworthy Packing
Delivery Time 75 days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Certification UL/FM/NFPA20 Flow 1000gpm
Pump NM Fire Motor Techtop 125HP
Head 145 PSI Supply Scope Fire Pump Pacakage
High Light

Skid Mounted Horizontal Split Case Pump


1000gpm Horizontal Split Case Pump


145PSI Skid Mounted Fire Pump

Leave a Message
Product Description

Horizontal Split Case Fire Pump Assembly Skid Mounted Fire Pump Package​



1. Main parts are all UL/FM products
2. Design and produce according to NFPA20 standard
3. Smaller sizes save place
4. Package tested in factory before shipping
5. Reduce on site work and material
6. Connecting the water and power on site, it can be immediately



Pump assembly SCF150-125-250 1000usgpm@145psi
Vacuum Manometer Φ100 -0.1~1.5bar
Pressure Gauge Φ100 0~25bar
Automatic Air Release 3410AR-116 1/2"
Motor assembly F-TXC444TS125U2B TEFC IP55
Cyclic pressure relief valve Cla-Val 55L-60 100-300PSI 3/4"
Check Valve
(Pump Discharge)
OS&Y Gate Valve (Discharge Control Valve) 6"
jockey Pump CDL2-16 10usgpm@109m 2900rpm/2.2kw
Circulation safety valve Cla-Val 55L-60 100-300PSI 3/4"
Vacuum Manometer Φ100 -0.1~1.5bar
Pressure Gauge ( Pressure Sensing Line ) Φ100 0~25bar
Isolation Valve (JockeyPump Discharge&Suction) Z41H PN25 DN25
Check Valve (Jockey Pump Discharge) H41H PN25 DN25
Pressure Gauge ( Pressure Sensing Line ) Φ100 0~25bar
Ball valve ( Pressure Sensing Line ) 1/2” PN16
Check Valve (Pressure Sensing Line ) H12 1/2” PN16
Motor Fire Pump Controller GPY-415-125/3/50-D29(NEMA3)
Pressure Maintenance Pump Controller(Jockey Pump) JP3-415-3/3/50-D8B(NEMA3)






































First-Class testing and inspection equipment.
UL certification represents the world's highest technical standards of fire certification,but also means that certified fire products

must withstand the most extreme,harsh test process,the purpose of certification designed to verify whether the product meets

the performance,safety and quality requirements,so as to achieve the purpose of property protection.
NM fire obtained fire diesel engine UL1247 and fire pump UL448 witnessed laboratory accreditation,fully proved that the

company in terms of hardware and software strength,are to meet the strict requirements of UL certification.
