2 Stage Vertical Turbine Fire Pump / Diesel Fire Fighting Water Pump High Speed

Place of Origin China
Brand Name CNP NM FIRE
Certification ISO/CCCF
Model Number 400VTP1250-36
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Standard Export Package
Delivery Time 35-40 Working Days
Payment Terms L/C, T/T
Product Details
Use Water;foam Concentrate Casing Ductile Cast Iron
Bearing Housing Cast Iron Speed 1760rpm
Head 114-76psi Standard NPFA20
High Light

vertical fire pump

,

vertical line shaft pump

Leave a Message
Product Description

2 Stage Vertical Turbine Fire Pump / Diesel Fire Fighting Water Pump High Speed



DEMANDS INFO FORM Kathy.pdf



vertical turbine pump is designed to successfully operate in a multitude of water sources from wells to oceans.


Markets served: Urban and rural municipal water, irrigation, chemical processing, primary metals, petroleum, power plants, mines, food processing, offshore platforms and more
Handles raw water intake, liquid transfer, cooling water circulation, booster service, storm water, flood control, marine, process services, volatile fluids, condensate, fuel pumps and mine dewatering
Turbine bowls can be staged in series to produce the necessary discharge pressures. Constructed out of cast iron, bronze, stainless steel or other machineable materials. Wear rings are available to provide a renewable surface. Open line shafts – Allows shaft bearings lubrication



The VTP pump line is normally designed to operate in wells or sumps. Its bowl assembly consists primarily of a suction case or bell, one or more pump bowls and a discharge case. The pump bowl assembly is positioned in the sump or well at a depth to provide the proper submergence.
Operation Limits
Capacity up to 13,636 m³/h (60,000 U.S. gpm)
Head up to 762 m (2,500 ft)
Maximum Pressure 74 bar (1,080 psi)
Temperature 0 to 121 ºC (32 to 250 ºF)
Applications Deep well, irrigation, sumps, condensate, can pump requirements, fire service, municipal, industrial



Applications
The vertical turbine pump is primarily used in cases where a submersible pump cannot be used because the flow exceeds the range of turbines. These types of pumps are also used to supply water to municipalities that depend on ground water instead of surface water, and to supply fire water and make-up water for industrial plants.



Where the fire protection water source is located below ground or deck level, the best technical pumping solution is the vertical suspended multi stage turbine pump. With this type of unit the impellers are fully immersed in the water maintaining prime at all times. The pumps are driven by vertical electric motors or by diesel engines through a right angle gearbox.



Advantage:





NM Fire is the firt member of NFPA from Chinese pump manufacturers. The production of fire pump groups is strictly in accordance with NFPA20, production process and performance testing also meet the requirement of ISO9001, some kinds of products have got APSAD (France), UL,FM and CCCF certificates.



We are the only enterprise in China that obtained not only UL and FM certificates, but CCCF as well, also the firt company in the world who was authorized by UL CCIC as witness testing center for both fire pump and fire fighting engines.
