High Precision Diesel Powered Fire Pump , Diesel Fire Fighting Pumps 2000GPM

Name: High Precision Diesel Powered Fire Pump , Diesel Fire Fighting Pumps 2000GPM
Brand: Wuhan Spico Machinery & Electronics Co., Ltd.
SKU: SCF200-150-460 （8x6")
Price: 32,500.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: CNP NM FIRE

Certification: NFPA20/UL/FM/EN12845/CCCF

Model Number: SCF200-150-460 （8x6")

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: Negotiation

Packaging Details: Export Packing

Delivery Time: 30-45 Working Days

Payment Terms: L/C, T/T

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                diesel driven fire pump, diesel engine fire pump


Certification::	UL/FM/NFPA20	Flow::	2000GPM
RPM:	1800 (60Hz)	Engine::	DE MAAS & NM Fire
Control Panel::	Tornatech (UL/FM)	Head:	120PSI

Certification::	UL/FM/NFPA20
Flow::	2000GPM
RPM:	1800 (60Hz)
Engine::	DE MAAS & NM Fire
Control Panel::	Tornatech (UL/FM)
Head:	120PSI

High Precision Diesel Powered Fire Pump , Diesel Fire Fighting Pumps 2000GPM

NFPA20/UL/FM Approval 2000GPM @ 120PSI Diesel Engine Drive Fire Pump With Horizontal Split case Fire Pump

Parameters:

HEAD

PUMP MODEL

SPEED

MAX SHAFT POWER

DIESEL ENGINE DRIVER

PSI

FEET

METER

RPM

MODEL

(NM&UL)

MODEL (DE

MAAS&FM)

120

277

SCF200-150-460
(8x6")

1800
(60Hz)

256

190.7

NM6-114

255

190

DF12TiH-F

338

252

Performance Ranges:

UL:	Q: 500-4000GPM	H:100-190PSI
FM:	Q: 500-4000GPM	H:100-190PSI
CCCF:	Q:20-500L/S	H:0.42-2.0Mpa
NFPA20:	Q: 300-8000GPM	H:60-300PSI

How it Works:

The most common split case pump is a single-stage, between bearing, non-self-priming centrifugal volute pump. The design of the pump allows for easy removal of the pump’s top casing to enable easy access to the pump’s components without interfering with the motor or the piping system.

The independent bearing casing allows for easy maintenance without the need for removing the pump’s top casing. The pump’s double volute design minimizes the radial load on the shaft, increasing component life and reducing vibrations to provide a quiet operation.

Product Type:

Diesel engine driven fire pump sets with air cooling & water cooling

NFPA20 Package

Advantage:

First-Class testing and inspection equipment.

UL certification represents the world's highest technical standards of fire certification,but also means that certified fire products must withstand the most extreme,harsh

test process,the purpose of certification designed to verify whether the product meets the performance,safety and quality requirements,so as to achieve the purpose of property protection.

NM fire obtained fire diesel engine UL1247 and fire pump UL448 witnessed laboratory accreditation,fully proved that the company in terms of hardware and software strength,are to meet the strict requirements of UL certification.

Service:

1. Any inquiries will be replied within 24 hours.

2. Dedicated to high quality, stable supply and considerate service.

3. Strict on raw material selection.

4. Reasonable & competitive prices with short lead time.
