High Power Electric Fire Fighting Pump, 200 GPM 140PSI UL FM Fire Pump

Place of Origin China
Brand Name NM FIRE
Certification UL /FM/Non-listed
Model Number End suction
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Export Packing
Delivery Time 60 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standards NFPA20, UL, FM Non-listed UL Performance Ranges Q: 100-750GPM H:70-152PSI
FM Performance Ranges Q: 100-750GPM H:70-152PSI Capacityt 200GPM
Controller Tornatech (UL/FM) Motor Techtop(UL)
High Light

single stage end suction pump

,

single stage fire pump

Leave a Message
Product Description
  • End Suction Centrifugal Pump Set Electric Fire Fighting Pump 200GPM 140PSI UL FM NFPA20 Fire Pump

    Product Details



Motor Pump Set UL LISTED
NM Fire End Suction Pump
Model ESF50/26 (UL) This Electric pump Set includes the pump(air relieve vlave , inlet & outlet gauges) , Motor, Control System,Commonbase .




Please contact me if you need other accessories.

Capacity 200GPM
Head 140PSI
RPM 2980rpm
Material:
Casing Ductile Cast iron
Impeller Bronze
Shaft SS420
Seal Gland packing
Wear ring Bronze
Bearing SKF
Engine: TECHTOP&UL
Model: TDC 286TS40U2B
  40HP/50HZ/380V/3PH
Controller : Tornatech (UL/FM)
Model: GPY - 380 /40 / 3 /50 / A4



Standards

NFPA20, UL, FM, EN12845,CCCF

Performance Ranges

UL : Q: 100-750GPM H:70-152PSI

FM: Q: 100-750GPM H:70-152PSI

CCCF: Q:15-45L/S H:0.6-0.9Mpa

NFPA20: Q: 100-3000GPM H:40-200PSI

High Power Electric Fire Fighting Pump,  200 GPM 140PSI UL FM Fire Pump 0



  • Application:


Large hotels, hospitals , schools,office buildings,supermarkets, commercial residential buildings, metro stations, railway stations, airports, kinds of transportation tunnels, petrochemical plants, thermal power plants, terminals, oil depots, large warehouses and industrial and mining enterprises, etc.


Please note :the pump will be not sold individual,it must be match with engine or electric motor driver.



High Power Electric Fire Fighting Pump,  200 GPM 140PSI UL FM Fire Pump 1



 High Power Electric Fire Fighting Pump,  200 GPM 140PSI UL FM Fire Pump 2
  • Five Advantages of CNP NM FIRE


①The late-mover advantage of products, we R&D better fire products than other Suppliers;

②Have the most complete and all series of fire pump models;

③Have listed diesel engines with self-owned brand--- NM FIRE;

④Understand the technology of fire- fighting products and fire- fighting system better than other competitors and have better services;

⑤Shorter delivery time.

  • FAQ


Q1.Do you have the UL-LISTED Fire Pump Sets?

Yes, We have the UL/FM and NFPA standard Fire Pump Sets.

Q2.I need your motor drive End-suction/Split-casing fire pump, what information shold I sent to you ?

Sir/Madam,you can privide the Capacity, Heed, Voltage and Frequncy,we will make the quotation for you,If you need Jockey Pump or other accessories, please tell us together.

Q3.If I need your Diesel Engine Drive End-suction/Split-casing fire pump, what information shold I sent to you ?

You can sent the Capacity Heed, Temperature and Altitude (temperature and altitude will affect the performance of diesel engines).If you need Jockey Pump or other accessories, please tell us Voltage and Frequncy or accessories together.

Q4.I need the UL/FM Vertical Tubine Fire Pump Set ,please sent me the price.

For the motor Diver Vertical Tubine Fire Pump Set: you shoul give us the Capacity, Heed, Voltage Frequncy and the tank deep.

For the Diesel Engine Drive Vertical Tubine Fire Pump Set:you should give us the Capacity, Heed and the tank deep.

If you need Jockey Pump or other accessories,please tell us together.


High Power Electric Fire Fighting Pump,  200 GPM 140PSI UL FM Fire Pump 3
  • Service:

1. Reply within 24 hours.
2. High-quality products and the most reasonable price
3. Data and chemical technology support.



High Power Electric Fire Fighting Pump,  200 GPM 140PSI UL FM Fire Pump 4
