Horizontal Diesel Engine Driven Fire Pump Centrifugal 1500GPM@140PSI

Place of Origin China
Brand Name CNP NM FIRE
Certification NFPA20/UL/FM/EN12845/CCCF
Model Number SCF200-150-460
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Export Packing
Delivery Time 45~60 Working Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Certification UL/FM/NFPA20 Flow 1500GPM
RPM 1800 (60Hz) Engine NM Fire
Control Eaton Color Red
High Light

diesel driven fire pump

,

diesel engine fire pump

Leave a Message
Product Description

1500GPM @ 140 PSI UL/FM Approval Diesel Engine Drive Split Case Pump for Fire Fighting Use



Parameters:



HEAD PUMP MODEL SPEED MAX SHAFT POWER DIESEL ENGINE DRIVER
PSI FEET METER RPM HP KW

MODEL

NM (UL Listed)

HP KW
140 323 98 SCF200-150-460
(8x6")
1800
(60Hz)
286 213.1 NM6-128 472 352



Performance Ranges:





UL:



 Q: 500-4000GPM  H:100-190PSI



FM:



 Q: 500-4000GPM  H:100-190PSI



CCCF:



 Q:20-500L/S  H:0.42-2.0Mpa



NFPA20:



 Q: 300-8000GPM  H:60-300PSI





Application:



Precision balancing of all factors in the design of CNP NMFIRE horizontal split case fire pump provide mechanical dependability, efficient operation and minimal maintenance. Simplicity of design ensures long efficient unit life, reduced maintenance costs and minimum power consumption.

Split case fire pumps are specifically designed and tested for fire service application around the world including:

Office buildings, hospitals, airports, manufacturing facilities, warehouses, power stations, oil and gas industry, schools/colleges, hotels, etc.



Special material for sea water pumping is available: Casing , impeller ,shaft ,shaft sleeve, wear ring—SS2205, Seal—Gland packing, Bearing—SKF



Product Type:



Diesel engine driven fire pump sets with air cooling & water cooling



NFPA20 Package





Advantage:



First-Class testing and inspection equipment.



UL certification represents the world's highest technical standards of fire certification,but also means that certified fire products must withstand the most extreme,harsh

test process,the purpose of certification designed to verify whether the product meets the performance,safety and quality requirements,so as to achieve the purpose of property protection.



Service:



1. Any inquiries will be replied within 24 hours.
2. Dedicated to high quality, stable supply and considerate service.
3. Strict on raw material selection.
4. Reasonable & competitive prices with short lead time.
