High Precision Centrifugal Fire Pump 358 Feet With 237.7kw Max Shaft Power

Place of Origin China
Brand Name CNP NM FIRE
Certification NFPA20/UL/FM/EN12845/CCCF
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Export Packing
Delivery Time 30-45 Working Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Certification UL/FM/NFPA20 Flow 1500GPM
RPM 2980 (50Hz) Engine DE MAAS & NM Fire
Control Panel Tornatech (UL/FM) Head 155PSI
High Light

diesel fire pump

,

ul fm approved fire pumps

Leave a Message
Product Description

UL/FM/NFPA20 Certification Split Case Centrifugal Fire Pump Capacity For Firefighting Applications





Horizontal split case pumps are the most common type of fire pump. These pumps are specifically designed and tested for fire service applications where reliability of performance is of vital importance. Split case pumps are characterized by: • Easy access to all working parts; • Rugged construction; • Liberal water passages; and • Efficient operation. Split case fire pumps are specified when the source of water is located above the surface of the ground and provides a positive suction pressure to the pump at any performance point. Single-stage or multistage pumps are available dependent upon discharge pressure requirements. Aurora split case fire pumps are built per the rigid standards of NFPA 20 and are listed by Underwriters Laboratories (UL) and approved by Factory Mutual (FM). Available in a broad range of operating pressures and flows from a minimum of 500 GPM, NM split case pumps can be driven by either an electric motor or diesel engine. NM’s UL-Listed, FM-Approved fire pump packages also include the system controller, with a full range of options and accessories available to complete the NFPA-compliant fire pump package.



Parameters:



HEAD PUMP MODEL SPEED MAX SHAFT POWER
PSI FEET METER RPM HP KW
155 358 109 SCF200-150-460
(8x6")
1800
(60Hz)
319 237.7





Operation Limits
Capacity up to 4,000 gpm Head up to 205psi
Applications: Commercial, municipal and residential high-rise buildings, Large industrial premises and storage warehouses, Offshore and remote facilities, Airports, Power stations.





Performance Ranges:





UL:



 Q: 500-4000GPM  H:100-190PSI



FM:



 Q: 500-4000GPM  H:100-190PSI



CCCF:



 Q:20-500L/S  H:0.42-2.0Mpa



NFPA20:



 Q: 300-8000GPM  H:60-300PSI







Product Type:



Diesel engine driven fire pump sets with air cooling & water cooling



NFPA20 Package





Advantage:



First-Class international technical standards.



CNP NM FIRE is the first member of NFPA from China pump's manufacturers.and won the UL,FM international fire certification for fire pump products.
