2500GPM 150PSI Split Case Fire Pump Diesel Engine TEFC IP55 IE3 Electrical Motor UL FM NFPA20 Water

Place of Origin China
Brand Name NM FIRE
Certification UL /FM/Non-listed/NFPA20
Model Number Split Case Pump
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Export Packing
Delivery Time 60 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standards NFPA20, UL, FM Non-listed Controller Tornatech/Eaton
Categories FIRE FIGHTING PRODUCTS, FIRE PUMP GROUP Capacity 5000GPM-~
Usage Fresh Water Or Sea Water Fuel Diesel/Electric
Motor Techtop/Marathon
High Light

Ductile Cast Iron Split Case Fire Pump

,

150PSI Split Case Fire Pump

,

IP55 Water Fire Pump

You can tick the products you need and communicate with us in the message board.
Item
End suction fire pump
Split case fire pump
Vertical turbine
Jockey pump
Electrical motor driven
Leave a Message
Item
Product Description
  • 2500GPM 150PSI SPLIT CASE FIRE PUMP DIESEL ENGINE TEFC IP55 IE3 ELECTRICAL MOTO FIRE PUMP UL FM NFPA20 WATER FIRE PUMP



Product Details

The system includes the main pump, diesel engine control cabinet, and others. For details, please refer to the table below.


Diesel Engine
Pump Set
( Heat Exchanger)
Pump: NMFIRE
Model: SCF250-200-450(UL/FM)
(10x8")
Q= 2500usgpm H=150psi n=1760 rpm

Material:
Casing---Ductile Cast iron
Impeller---SS304
Shaft--- AISI 4340
Shaft sleeve---SS304
Seal------ Gland packing
Wear ring----Bronze
Bearing---SKF
This Diesel Engine Group includes:
1. the pump(air relieve valve, inlet & outlet gauges);
2. Diesel Engine;
3. Commonbase;
4.Residencial type Silencer;
5. Flexible exhaust connector;
6. Coupling;
7. Cooling System;
8. Control System;
9. Main relief valve;
10. Waste cone;
11. Fuel tank;
12. Test Fee.

Batteries are excluded due to China's customs restrictions.
Engine: NMFIRE(UL/FM)
Model: NM6-135B
252kw at 1760rpm
Fuel tank :NFPA 20 Compliant-non-approved Capacity: 1500L Double wall
Model : NMTY-YX-1500L-00-01
Controller : Tornatech(UL/FM)
Model: GPD24-220-C05
Main relief valve : Cla-val (UL/FM)
Model: 2050B-4KG1 6" 100-300psi
Waste cone: NMFIRE
Model: 6"-10"
Motor Pump Set Pump: NMFIRE
Model: SCF250-200-350(UL/FM)
(10x8")
Q= 2500usgpm H=150psi n=2980 rpm

Material:
Casing---Ductile Cast iron
Impeller---SS304
Shaft--- AISI 4340
Shaft sleeve---SS304
Seal------ Gland packing
Wear ring----Bronze
Bearing---SKF
This Electric pump Set includes:
1. the pump(air relieve valve , inlet & outlet gauges);
2. Motor;
3. Coupling;
4. Commonbase;
5. Control System;
6. Circulation safety valve;
7. Test Fee.
Motor: Marathon(UL)
Model: 449TS-2
300HP/50HZ /400V/ 3PH/NEMA/TEFC/IP55/IE3
Control Panel: Tornatech (UL/FM)
Model: GPY-400/300/3/50
Circulation safety valve: Cla-val (UL/FM)
Model: 55L-60 3/4" 100-300psi





The above is one of our configurations, and it can also be customized according to your needs.

You can leave me a message for your specific needs, and I will reply to you in time; or download the info and send it to my email address, in the upper right corner of the form.

DEMANDS INFO FORM Tarik.pdf



You can send me your actual needs in detail, and I will customize and design suitable products for you according to your needs.





2500GPM 150PSI Split Case Fire Pump Diesel Engine TEFC IP55 IE3 Electrical Motor UL FM NFPA20 Water 0



2500GPM 150PSI Split Case Fire Pump Diesel Engine TEFC IP55 IE3 Electrical Motor UL FM NFPA20 Water 1

ABOUT US

CNP NM FIRE-fighting System Co., Ltd is a leading manufacturer of fire pumps, diesel engines, controllers, diesel engine driven fire pump sets, electric motor driven fire pump sets, fire pump package systems, and containerized fire pump package systems in accordance with domestic & international standards. We are a member of the National Fire Protection Association (NFPA) and the European Fire Sprinkler Network (EFSN). The technical team consists of a number of engineers and foreign experts who have more than 20 years of experience in research and development for global fire-fighting equipment. We can offer you a wide range of fire pumps and diesel engines which have gotten UL, FM(America), APSAD(France), SETSCO(Singapore) certificates that meet every fire protection needed.

Our mission is to produce the highest standard products with advanced technology to "Protect life, love and history" for the big world.



NM Fire University



NM Fire is the first member of NFPA from Chinese pump manufacturers. jointly built ‘Fire Pump Technology Training Center’ together with Domestic Fire Protection Association and Overseas Certificate Authority for further utilizing global advanced fire pump technology and changing the backward situation of the fire pump field.

The training center is currently being built. NM Fire especially completed a standard package system for the training center in accordance with NFPA20, which can be used for on-the-spot teaching and practical operation training.



Trainees:

Designers from firefighting engineering company and designing institute

Government employees who engage in fire control management

Fire pump dealers

Fire pump group end-users and operators



What can you get from the training?

Operating principles of the package system

Operating procedure of package system

Technical standard and technology training for fire pumps firefighting diesel engines and controllers etc.

Training for the latest NFPA 20 standard

Simple troubleshooting in the NFPA20 package system.



Five Advantages of CNP NM FIRE


① The late-mover advantage of products, we R&D better fire products than other Suppliers;

② Have the most complete and all series of fire pump models;

③ Have listed diesel engines with self-owned brand--- NM FIRE;

④ Understand the technology of fire- fighting products and fire- fighting system better than other competitors and have better services;

⑤ Shorter delivery time.

Certificates

Our products are manufactured to the highest standards in the fire fighting market

Split Case Pump: UL Listed and FM approved, Flow range:300gpm-8000gpm

End Suction Pump: UL Listed and FM approved, Flow range:50gpm-750gpm

Vertical In-Line Pump: Flow range:50-1500gpm

Vertical Turbine pump: UL Listed and FM approved, Flow range:100gpm-7000gpm

Diesel Engine:UL Listed and FM approved,Power range: 51hp-1207hp
