1500GPM Electric Motor Split Case UL FM Centrifugal Fire Pump

Place of Origin China
Brand Name CNP NM FIRE
Certification UL /FM/NFPA20
Model Number SCF200-150-310(8x6")(UL/FM)
Minimum Order Quantity 1set
Price Negotiation
Packaging Details Export Packing
Delivery Time 60 Days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Motor TECHTOP&UL Driving Motor Driver
Controller Tornatech (UL/FM) Capacity 1500usGPM
Head 95m Engine TECHTOP&UL
High Light

UL FM Centrifugal Fire Pump

,

1500GPM Centrifugal Fire Pump

,

Electric Motor Split Case Fire Pump

Leave a Message
Product Description
  • 1500GPM@95M Electrical Motor Driven UL FM Approved Fire Pumps Split Case Centrifugal Pump For Fire Fighting

Product Details


NMFIRE is the first NFPA (National Fire Protection Association) member in China's pump industry and also the only Chinese company among the members of EFSN (European Fire Sprinkler Network). We are the first company in China to receive both UL and FM certifications and the only company in the world to manufacture UL/FM certified fire pumps and UL/FM diesel engines. Our company was a key contributor to the revision of China's fire pump industry standards. Our product technology and range in products are industry-leading in both the domestic and global marketplace.

Our mission is to produce the highest standard products with advanced technology to "Protect life, love and history" for the big world.



Motor Pump Set Pump:
Model:SCF200-150-310(8x6")(UL/FM)
Q=1500usgpm H=95m n=2980rpm
Material:
Casing---Ductile Cast iron
Impeller---SS304
Shaft--- AISI 4340
Shaft sleeve---SS304
Seal------ Gland packing
Wear ring----Bronze
Bearing---SKF
Motor: Techtop(UL)
Model: F-TXC445TS150U2B
150HP/50HZ /400V/ 3PH
Control Panel: Tornatech (UL/FM)
Model: GPY - 400 / 150 / 3 / 50
Circulation safety valve(UL@FM)
Model: Cla-Val 55L-60
Jockey Pump Set Pump: NM FIRE(Non-listed)
Model: CDL8-10
Q= 26usgpm H=100 m 2POLE 4KW
Control Panel: Tornatech(UL Listed)
Model:JP3 - 400 /5.5/ 3 /50
1500GPM Electric Motor Split Case UL FM Centrifugal Fire Pump 0

Standards


NFPA20, UL, FM, EN12845,CCCF

Performance Ranges

UL : Q: 100-750GPM H:70-152PSI

FM: Q: 100-750GPM H:70-152PSI

CCCF: Q:15-45L/S H:0.6-0.9Mpa

NFPA20: Q: 100-3000GPM H:40-200PSI



Application


Large hotels, hospitals, schools,office buildings,supermarkets, commercial residential buildings, metro stations, railway stations, airports, kinds of transportation tunnels, petrochemical plants, thermal power plants, terminals, oil depots, large warehouses, and industrial and mining enterprises,seawater pumping, etc.

Special material for seawater pumping is available: Casing, impeller, shaft, shaft sleeve, wear ring—SS2205, Seal—Gland packing, Bearing—SKF.
  • Five Advantages of CNP NM FIRE



① The late-mover advantage of products, we R&D better fire products than other Suppliers;


② Have the most complete and all series of fire pump models;


③ Have listed diesel engines with self-owned brand--- NM FIRE;


④ Understand the technology of fire- fighting products and fire- fighting system better than other competitors and have better services;


⑤ Shorter delivery time.

1500GPM Electric Motor Split Case UL FM Centrifugal Fire Pump 1

UL/FM certificates​


 our Listed pump and Standard fire pump

Pump: UL 448 FM1311

Engine: UL 1247 FM1333

Package according to NFPA20

In addition to the above models, there are many model UL/FM testing in process.

Looking forward to your enquiry.

 1500GPM Electric Motor Split Case UL FM Centrifugal Fire Pump 2
Basic parameters


Rated Flow:

Rated Head:

Frequency and voltage:

Medium:(Freshwater/ Seawater):

Jockey Pump set:

Rated Flow:

Rated Head:

Frequency and voltage:




1500GPM Electric Motor Split Case UL FM Centrifugal Fire Pump 3
