Fire Fighting Double Suction Horizontal Split Case Pump 500 GPM UL Listed
| Place of Origin | China |
|---|---|
| Brand Name | CNP NM FIRE |
| Certification | UL Listed FM Approved |
| Model Number | SCF125-80-350 (5x3") |
| Minimum Order Quantity | 1set |
| Price | Negotiation |
| Packaging Details | Standard Export Packing / Plywood Package |
| Delivery Time | 35-40 Working Days |
| Payment Terms | L/C, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Color | Red | Casing | Ductile Cast Iron |
|---|---|---|---|
| Bearing | SKF | Function | Fire Fighting |
| Type | Centrifugal Pump | Flow | 500usgpm |
| High Light | ul listed fire pumps,horizontal split case fire pump |
||
Product Description
UL Listed 500PM @ 115 PSI Horizontal Split Case Pump For Firefighting Usage
The Split Case Fire Pump is designed to provide water to stand pipe, sprinkler, chemical mitigation and hydrant systems for fire supression in industrial and commercial facilities.
Features and Benefits:
Available in capacities up to 4,000 GPM
Pressures up to 205 PSI
In compliance with NFPA #20, UL or FM
Performance and hydrostatic tests.
Dynamic balance impellers.
Space saving design.
Easy maintenance and upkeep.
Available in electric or diesel engine driven models.
Features and Benefits:
Available in capacities up to 4,000 GPM
Pressures up to 205 PSI
In compliance with NFPA #20, UL or FM
Performance and hydrostatic tests.
Dynamic balance impellers.
Space saving design.
Easy maintenance and upkeep.
Available in electric or diesel engine driven models.
Parameters:
| HEAD | PUMP MODEL | SPEED | MAX SHAFT POWER | |||
| PSI | FEET | METER | RPM | HP | KW | |
| 115 | 266 | 81 | SCF-125-80-350 (5X3") | 2980 (50Hz) |
69 | 51.4 |
KEY FEATURES
- Complete compact unit
- Horizontal
- Tailored to the customer's required standards and specifications
- Configuration for NFPA20 / FM / UL up to 4000 US gpm
- Good suction characteristics, also with higher speeds
- Practically no limitations on flow
- Less wear and tear influences
- Easy maintenance without interfering on piping / driver
- Select Models Available in alternate materials with FM approval
Performance Ranges:
|
UL:
|
Q: 500-4000GPM | H:100-190PSI |
|
FM:
|
Q: 500-4000GPM | H:100-190PSI |
|
CCCF:
|
Q:20-500L/S | H:0.42-2.0Mpa |
|
NFPA20:
|
Q: 300-8000GPM | H:60-300PSI |
Application:
HSC Pumps are engineered for reliable operation upon demand. All fabricated parts are standardized and accurately machined for true alignment, increasing overall durability. Precision balancing of all rotating components provides mechanical dependability, reliable operation and minimal maintenance. Impellers are constructed with double inlets that practically eliminate end thrust while boosting operating efficiency.ic tests.
Advantage:
First-Class international technical standards
NM Fire is the first member of NFPA from Chinese pump manufacturers .
The production of fire pump groups is strictly in accordance with NFPA20, production process and performance testing also meet the requirement of ISO9001, some kinds of products have got APSAD(France), UL , FM and CCCF certificates.
We are the only enterprise in China that obtained not only UL and FM certificates, but CCCF as well,also the first company in the world who was authorized by UL CCIC as witness testing center for both fire pumps and fire fighting engines.
The Split Case Fire Pump is designed to provide water to stand pipe, sprinkler, chemical mitigation and hydrant systems for fire supression in industrial and commercial facilities.
