Home > products > Diesel Engine Driven Fire Pump > NFPA20 Standard Diesel Engine Driven Fire Water Pump For Residential / Industrial

NFPA20 Standard Diesel Engine Driven Fire Water Pump For Residential / Industrial

Product Details

Place of Origin: China

Brand Name: NM FIRE

Certification: NFPA20/UL/FM/EN12845/CCCF

Model Number: ESF65/26 (2.5"x2")

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: Negotiation

Packaging Details: Export Packing

Delivery Time: 30-45 Working Days

Payment Terms: L/C, T/T

Get Best Price
Highlight:

diesel driven fire pump

,

diesel powered fire pump

Certification::
UL/FM/NFPA20
Flow::
400gpm
Head:
8bar
Engine::
NM Series
Control Panel::
Tornatech (UL/FM)
Color:
Red
Certification::
UL/FM/NFPA20
Flow::
400gpm
Head:
8bar
Engine::
NM Series
Control Panel::
Tornatech (UL/FM)
Color:
Red
NFPA20 Standard Diesel Engine Driven Fire Water Pump For Residential / Industrial

NFPA20 Standard Diesel Engine Driven Fire Water Pump For Residential / Industrial





Parameters:



Pump NM Fire End Suction
Type ESF65/26
Speed 2950rpm
Rated flow 400gpm
Raged head 80m
Engine NM Fire NM4-105 (70kw)
Fuel tank 400 L
Controller Tornatech GPD24-220-C05




Applications:



The end suction centrifugal pump is useful in various residential, industrial and commercial applications. Due to the fact that the pumps are highly common and readily available from many suppliers, their prices are usually very attractive.



Standard end suction centrifugal water pumps are normally close coupled and manufactured from standard iron or a variety of plastics. Pumps that are meant for more heavy duty commercial and industrial applications are often mounted on a bedplate with a coupling that separates the motor and the pump.



These are usually available in stainless steel and more exotic alloys or plastics for corrosion resistance, while others are manufactured from hardened iron for mining, slurry and dredging applications.



NFPA20 Standard Diesel Engine Driven Fire Water Pump For Residential / Industrial 0



Advantage:



First-Class testing and inspection equipment.



UL certification represents the world's highest technical standards of fire certification,but also means that certified fire products must withstand the most extreme,harsh test process,the purpose of certification designed to verify whether the product meets the performance,safety and quality requirements,so as to achieve the purpose of property protection.

NM fire obtained fire diesel engine UL1247 and fire pump UL448 witnessed laboratory accreditation,fully proved that the company in terms of hardware and software strength,are to meet the strict requirements of UL certification.



Performance Ranges:





UL:



 Q: 100-750GPM  H:100-145PSI



FM:



 Q: 100-750GPM  H:100-145PSI



CCCF:



 Q:5-150L/S  H:0.40-1.6Mpa



NFPA20:



 Q: 100-2250GPM  H:60-230PSI





Service:



Pre-service
Introduce the product to the customer in detail,answer the question raised by customer carefully;
Sale service
1.Ensure product with high quality and pre-commissioning before delivery;
2.Delivery on time;
3.Provide full set of documents as customer’s requirements.
After-sale service
Provide considerate services to minimize clients’ worries.



NFPA20 Standard Diesel Engine Driven Fire Water Pump For Residential / Industrial 1
