Horizontal End Suction Electric Motor Driven Fire Pump 68.2M3/H 60m UL FM NFPA20

China Horizontal End Suction Electric Motor Driven Fire Pump 68.2M3/H 60m UL FM NFPA20 supplier

Large Image :  Horizontal End Suction Electric Motor Driven Fire Pump 68.2M3/H 60m UL FM NFPA20

Product Details:

Place of Origin: China
Brand Name: NM FIRE
Certification: UL /FM/Non-listed
Model Number: End suction

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: Export Packing
Delivery Time: 60 Days
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
Standards: NFPA20, UL, FM Non-listed UL Performance Ranges: Q: 100-750GPM H:70-152PSI
FM Performance Ranges: Q: 100-750GPM H:70-152PSI Capacityt: 68.2M3/H
Head: 60m Motor: TECHTOP&UL

  • UL FM NFPA20 Fire Fighting Pump water pump 68.2M3/H 60m horizontal End suction fire pump set electric pump

    Product Details

Motor Pump Set UL LISTED
NM Fire End Suction Pump
Model ESF65/20 (UL) This Electric pump Set includes the pump(air relieve vlave , inlet & outlet gauges) , Motor, Control System,Commonbase .




Please contact me if you need other accessories.

Capacity 68.2M3/H
Head 60m
RPM 2980rpm
Material:
Casing Ductile Cast iron
Impeller Bronze
Shaft SS420
Seal Gland packing
Wear ring Bronze
Bearing SKF
Engine: TECHTOP&UL
Model: TDC 286TS40U2B
  40HP/50HZ/380V/3PH
Controller : Tornatech (UL/FM)
Model: GPY - 380 /40 / 3 /50 / A4



Standards

NFPA20, UL, FM, EN12845,CCCF

Performance Ranges

UL : Q: 100-750GPM H:70-152PSI

FM: Q: 100-750GPM H:70-152PSI

CCCF: Q:15-45L/S H:0.6-0.9Mpa

NFPA20: Q: 100-3000GPM H:40-200PSI

Horizontal End Suction Electric Motor Driven Fire Pump 68.2M3/H 60m UL FM NFPA20

  • Application:



Large hotels, hospitals , schools,office buildings,supermarkets, commercial residential buildings, metro stations, railway stations, airports, kinds of transportation tunnels, petrochemical plants, thermal power plants, terminals, oil depots, large warehouses and industrial and mining enterprises, etc.


Please note :the pump will be not sold individual,it must be match with engine or electric motor driver.
  • About NM Fire:



CNP NM Fire-fighting System Co.,Ltd(Hereinafter referred to as NM Fire)is the subsidiary of Nanfang Zhongjin Environment Co., Ltd, NM Fire is located in Hunan Changsha Economic and Technological Development Zone, mainly produce and sell Diesel engine &Motor fire pump groups , controllers and fire pumps which are in accordance with domestic & international standards and have gotten related certifications . NM Fire is the member enterprise of NFPA, the technical team consists of a number of engineers and foreign experts who have more than 20 years of experience in research and development for global fire-fighting equipments. There are several models have gotten UL,FM(America), APSAD(France), Setsco(Singapore)certificates.

The company’s mission is to protect the community fire safety, in line with the spirits of “integrity, win-win”, glad to provide high cost-effective products and high-quality service for our customers.


  • Five Advantages of CNP NM FIRE


①The late-mover advantage of products, we R&D better fire products than other Suppliers;

②Have the most complete and all series of fire pump models;

③Have listed diesel engines with self-owned brand--- NM FIRE;

④Understand the technology of fire- fighting products and fire- fighting system better than other competitors and have better services;

⑤Shorter delivery time.

Horizontal End Suction Electric Motor Driven Fire Pump 68.2M3/H 60m UL FM NFPA20

  • FAQ



Q1.Do you have the UL-LISTED Fire Pump Sets?

Yes, We have the UL/FM and NFPA standard Fire Pump Sets.

Q2.I need your motor drive End-suction/Split-casing fire pump, what information shold I sent to you ?

Sir/Madam,you can privide the Capacity, Heed, Voltage and Frequncy,we will make the quotation for you,If you need Jockey Pump or other accessories, please tell us together.

Q3.If I need your Diesel Engine Drive End-suction/Split-casing fire pump, what information shold I sent to you ?

You can sent the Capacity Heed, Temperature and Altitude (temperature and altitude will affect the performance of diesel engines).If you need Jockey Pump or other accessories, please tell us Voltage and Frequncy or accessories together.

Q4.I need the UL/FM Vertical Tubine Fire Pump Set ,please sent me the price.

For the motor Diver Vertical Tubine Fire Pump Set: you shoul give us the Capacity, Heed, Voltage Frequncy and the tank deep.

For the Diesel Engine Drive Vertical Tubine Fire Pump Set:you should give us the Capacity, Heed and the tank deep.

If you need Jockey Pump or other accessories,please tell us together.
